Raptor 90 2020 Sports Quad Bike Review Specs Price

Raptor 90 2020 Sports Quad Bike

The new Raptor 90 2020 Sports Quad Bike is an ideal ATV for young riders, and it has electric start, reversing, and legendary Raptor style, which is fun for riders over ten years old. Following is the full review of 2020 Raptor 90 with its price and specifications.

Raptor 90 2020 Sports Quad Bike – Features and Price

Popular Features

Raptor 90 2020 Sports Quad Bike is manufactured to bring the most fun to the ATV category for teenagers aged ten and above. Its low-maintenance 90cc engine has been tuned to produce excellent mid-to-low-end performance. In this area, it also has remarkable features, such as a fully automatic CVT gearbox with reverse gear, a gated shifter, and electric start with back up kick start-all of which are standard.

Raptor 90 2020 Sports Quad Bike

Thanks to tool-free quick access to the air filter element and other functions, maintenance is also straightforward. The compact A-arm front suspension has been optimized to provide light, sporty steering and comfortable ride quality. The preload-adjustable shock absorber offers 5.0 inches of wheel travel and adds to the Raptor 90’s full-size ATV appearance.

The rear swingarm also has a 5-way preload adjustable shock absorption function, which can provide 5.7 inches of wheel travel. The advanced frame design combines a large 1.7-gallon fuel tank, luxurious seats, and a spacious integrated floor in a long and robust wheelbase. The Raptor 90 uses low-profile Duro tires on its lightweight wheels, adding a sporty look and handling, while the powerful Raptor 700R undoubtedly inspires its shape.

Raptor 90 2020 Sports Quad Bike

Engine

The 90cc four-stroke SOHC engine has been adjusted to provide excellent mid- and low-end performance where needed. The motor adopts air cooling to simplify operation, improve performance and extend service life, and take ultra-reliable wet oil pan lubrication. Of course, push-button electric start is standard, and the storage position under the seat also provides an emergency start starter, which makes you more worry-free. Maintenance is also easy with quick tool-free access to functions such as the air filter element.

The new fully automatic, continuously variable transmission (CVT) simply means no speed change. Very convenient for all riders, this is a feature that entry-level riders particularly like. The standard reverse operation simplifies the maneuvering of the Raptor 90. The engine power is delivered to its rear wheels through the tried-and-tested O-ring chain drive. The chain drive runs along the rocker arm, which is set at the optimal angle to achieve rear shock absorption.

Raptor 90 2020 Sports Quad Bike

Chassis / Suspension

The compact A-arm front suspension has been optimized to provide light, sporty steering and comfortable ride quality. The preload-adjustable shock absorber offers 5.0 inches of wheel travel and adds to the Raptor 90’s full-size ATV appearance. Less. The rear swingarm also has a 5-way preload adjustable shock absorption function, which can provide 5.7 inches of wheel travel.

The design of the Raptor 90 makes all riders feel comfortable. The spacious, ergonomic design, luxurious seats, and large floor allow riders ten years and older to adapt to more significant displacement when they are older, without exceeding the size of the machine. To obtain the constant braking force, three sealed drum brakes make the Raptor 90 stop quickly. There is also a unique parking brake mounted on the handlebar.

Raptor 90 2020 Sports Quad Bike

Additional Features

The CDI system means reliable ignition performance, durable and efficient sparks, and a sealed, maintenance-free battery that can provide worry-free service. The reversing and reversing indicators installed on the handlebars also keep the rider informed. Raptor 90 has a powerful Raptor 700R, which undoubtedly provides a sporty look and high fender.

Raptor 90 2020 Sports Quad Bike

Raptor 90 2020 Sports Quad Bike – Price

The new 2020 Raptor 90 is available at $2,999 with Yamaha Blue Team and White color combination.

Raptor 90 2020 Sports Quad Bike

Raptor 90 2020 Sports Quad Bike – Technical Specifications

Engine

Engine Type 90cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 47 mm x 51.8 mm
Compression Ratio 9.2:1
Fuel Delivery Carburetor
Transmission CVT; F, N, R
Final Drive Chain

Raptor 90 2020 Sports Quad Bike Specs

Chassis

Suspension / Front Single A-arm; 5.0 inches travel
Suspension / Rear Monoshock swingarm; 5.7 inches travel
Brakes / Front Dual drum
Brakes / Rear Drum
Tires / Front AT18 x 7-8
Tires / Rear AT18 x 9-8

Raptor 90 2020 Sports Quad Bike Specs

Dimensions

L x W x H 58.5 inches x 40.2 inches x 37.6 inches
Seat Height 29.5 inches
Wheelbase 40.6 inches
Turning Radius 3.9 inches
Fuel Capacity 1.7 gallons
Wet Weight 279 lb

Raptor 90 2020 Sports Quad Bike Specs

Other

Warranty 6 Month (Limited Factory Warranty)

Raptor 90 2020 Sports Quad Bike

Conclusion

2020 Yamaha Raptor 90 is designed to bring maximum fun to youth ATV classes ten years old and above. Driver safety is our top priority. The Raptor 90 2020 Sports Quad Bike can only be ridden by riders ten years and older. This machine is one of the best youth ATVs ever.
