2023 Yamaha TT-R230 Dirt Motorcycle Review Specs Price

The 2023 Yamaha TT-R230 Dirt Motorcycle is a high-performance motorcycle that is both user-friendly and durable.

2023 Yamaha TT-R230 Dirt Motorcycle

2023 Yamaha TT-R230 Dirt Motorcycle – Features and Specs

Key Features

The 2023 Yamaha TT-R230 Dirt Motorcycle is a superb option for beginning and intermediate riders because of its YZ-inspired styling and sturdy 223cc air-cooled SOHC four-stroke engine that generates reliable, broad power. The flat seat and tank junction are reminiscent of race bikes, positioning the rider for maximum freedom of movement. The electric start makes starting the machine as easy as pushing a button. It is a serious trail bike that can be ridden by many riders thanks to its low seat height, long-travel suspension, and 11.6-inch ground clearance. Sturdy, condensed body great control and durability come from the steel diamond-shaped frame.

2023 Yamaha TT-R230 Dirt Motorcycle


The 223cc air-cooled SOHC four-stroke produces power that is both widespread and smooth, making it suitable for riders of all skill levels and a wide variety of terrains. The electric start is very dependable and allows for instantaneous use. The six-speed gearbox and heavy-duty clutch are optimized for flexibility and efficiency. The CDI magneto ignition technology Digital Ignition uses is very dependable and requires very little maintenance. The YZ design of the air filter is both low-maintenance and efficient. The lightweight exhaust has a USFS-approved spark arrestor and a silent silencer. An automatic cam chain tensioner requires little upkeep and extends the engine’s life.

2023 Yamaha TT-R230 Dirt Motorcycle


Excellent maneuverability and responsive handling are provided by the steel frame’s short wheelbase and low seat height, making it suitable for riders of varying skill levels. Superior Suspension in the Back, 8.7 inches of smooth, progressive rear wheel travel is provided by an adjustable rear shock attached through a linkage, making for excellent bump absorption and handling. Fork in Front, Trail-Ready With 9.4 inches of wheel travel and a 36mm front fork, you’ll have comfortable, reliable control over rugged terrain. With an impressive 11.6 inches of ground clearance, you can conquer any terrain. The snail-type chain adjusters on the swingarm’s aluminum box part make adjusting the chain a breeze. Braking with Two Discs Strong and reliable stopping power is provided by the 220mm front disc and 130mm rear drum brakes. Total sizing Knobby tires give motocross-level grip, while 21-inch front and 18-inch rear aluminum wheels reduce unsprung weight.

2023 Yamaha TT-R230 Dirt Motorcycle

Additional Features

The rider may sit low and relax on the long gripper seat without restricting their range of motion. Colors and logos from Team Yamaha, as well as number plates on the front and sides, provide this motocross look. Pegs That Don’t Slip Footing is never an issue, no matter how wet or muddy the ground is, thanks to the large, collapsible foot pegs with studs. Protection for the Fork Seal and Stanchion Tubes Robust fork boots provide excellent protection for the fork seal and stanchion tubes.

2023 Yamaha TT-R230 Dirt Motorcycle – Technical Specifications


Type 223cc air-cooled, SOHC 4-stroke; 2 valves
Bore x Stroke 70mm x 58mm
Compression Ratio 9.5:1
Fuel Delivery Carburetor
Ignition CDI
Transmission Constant-mesh 6-speed; multi-plate wet clutch
Final Drive Chain

2023 Yamaha TT-R230 Dirt Motorcycle

Chassis Suspension Brakes

Suspension / Front Telescopic fork; 9.4-in travel
Suspension / Rear Single shock; 8.7-in travel
Brakes / Front Hydraulic single disc, 220mm
Brakes / Rear Drum, 130mm
Tires / Front 80/100-21
Tires / Rear 100/100-18


L x W x H 81.3 inches x 31.5 inches x 46.5 inches
Seat Height 34.3 inches
Wheelbase 54.5 inches
Rake (Caster Angle) 27.0-degree
Trail 4.4 inches
Ground Clearance 11.6 in
Fuel Capacity 2.1 gal
Fuel Economy n/a
Wet Weight 251 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue
