KTM 450SXF Factory Edition 2014

2014 KTM 450 SXF

Projected value for the Bike in near future is round about $10,000. Be the one to enjoy an exciting ride on KTM 450 SXF dirt bike.
With the construction of the newest 450 SX-F by the KTM, the company proposes a champion bike (victory bike) that appeals prospective after an engine (which is largely displaced) and a framework which is faultlessly adjusted to handle and control its underdone power and influence. Ryan Dungey a quite famous one, has cast off it to win the AMA 450 Motor Cross-country Championship and found unconditionally no cause to alter bikes in imperative to protect his designation and title. It is the correct selection for every motocross rider who is in search for excellent rotation and control with lots of rheostat for competing. 2014 ktm 450 sxf dirt bike horsepower comprises of such a powerful engine that is highlighted with the major four points mentioned below.

KTM 450 SXF 2014


The details of these points is explained earlier under the review for dirt bike KTM 450SXF 2014 at www.bikescatalog.com

Framing For KTM 450SXF:

When we talk about the frame for the new KTM 450SXF it is to be announced proudly that it is constructed with the high-tech and most advanced frame design which is lightweight, strength highly with chromo steel units associated for the provision of maximum longitudinal toughness with finest torsional firmness. It assures stress-free control and detailed confronting along with the exceptional steadiness.

KTM 450 SXF 2014 specs

Suspension for KTM 450SXF:

On the account of suspension for this newest bike it is exceptional to announce that the rear mono shock along with the 48mm inverted front fork of the WP Suspension which assured the finest reaction and curbing features. In 2014, the fork has more investments in contradiction of bottoming out, thank you to their enhanced setting. For sure the firmness and recoil damping can be attuned to the trajectory circumstances and the rider’s partialities with a spiral of the wrist – the rear mono shock has even separated high and low speed modifications.

Swing Arm for KTM 450SXF:

The swing arm is constructed consuming the up-to-date in calculation and recreation software, the strategy and wall wideness of the troupe aluminum swing arm have been enhanced for least weight at finest toughness and accurately demarcated flexibly that offers flawless steadiness at least burden. For 2014, the concocts of bike constructions have reviewed the shackle guide to intensify the dependability while dropping the weight.

2014 KTM 450 SXF

2014 KTM 450sxf Exhaust:

The new 450SXF is having an enhanced and more improved silencer that attains exceptional performance at low sound levels.

Wheels for KTM 450SXF:

The wheels of the bike are manufactured in a way that they use inconsequential, CNC-machined pivots, high-end Best brims and the rods glazed in black with light in weight aluminum nipples to attain supreme constancy at lowest weight. The OEM Dunlop Geomax MX51 exhausts to transport flawless power, grip and exceptional performance.

Brakes for KTM 450SXF:

KTM 450 SXF breaks

The grip of the newest bike is managed with the use of High-Tech Brembo brakes which have continuously been known and named as average apparatus on KTM off-road motorbikes. Joined with the lightweight Wave discs, they are the eventual answer in decelerating skill or barking skills. The model SX attains a newly-developed chief cylinder with a new tank, a lesser width piston and enhanced pedal kinematics. In connection with the improved brake pads, this makes an exceptional enhancement in the front brake performance and stroke.


For 2014, KTM 450sxf has enhanced its equipment projection geometry to deliver its clients with a light in weight 5-speed gearbox through an exceptionally amplified stability.


The model 450 SX-F hires the KTM-developed DDS (Damped Diaphragm Steel) clutch with a wear-free steel bag and tremendously temperature impervious clutch plates. This strategy is illustrious by engaging a diaphragm spring as an alternative of the usual coil springs, which makes a significantly calmer clutch action. Supported for 2013, the diaphragm spring also leaves satisfactory space for a damping system incorporated into the seize core, which assistances both grip and stability.


2014 KTM 450 SX-F

In amalgamation with the ground-breaking injector spot as industrialized by KTM, the Keihin Engine Management System, with electronic fuel inoculation and 44mm regulate body delivers the engine with a spur-of-the-moment reaction and extreme performance. For 2014, the electric wiring yoke of the 450SXF has been additionally shortened and even sophisticated class wires and connectors are cast-off. In order to defend them against compression washers, many connectors are now walled in new rubber waders. With a non-compulsory map-select switch from the KTM Power Parts program, EMS remains to permit the selection of the different engine features.


The 450SXF 2014 is close-fitted with a power-driven meze as standard – a clear improvement when it comes to crux time in the warmth of battle. In 2014, a newly-developed cruise rally is used to escalate the stability.


KTM 450 SXF 2014 engine

The dense 60 hp power pack with a solitary camshaft and the newest electrical petroleum inoculation is eminent by unequaled performance and an extremely well-organized power distribution. Appreciations are to be made to the newly reviewed cranks case where the weight is condensed for the year 2014.


Seat for the bike is perfect in case of having exceptional ergonomics; the seat has established a better-quality spume chiefly guaranteeing grander luxury and robustness.


All the models in t    the SX range has an innovative, polythene tank which is light in weight having a capability to store 1.98 gallons. The new filler cap with the private filaments is made for a stress-free and trustworthy finishing. The 4-stroke models have the equal system for the fuel pump as the 4-stroke Enduro models, which make it stress-free to fit a superior tank from the Power Parts program.
All models of SX are trimmed with the excellent strong and elongated Renthal Fatbar 827 whose twist is exclusively finely well-matched for the necessities of motocross. The verified usual KTM base permits to repair the handlebar in four diverse spots. A large Renthal smash pad in a stylish and elegant grouping of black and silver, offers an effective crash shield for the rider.

2014 KTM 450sxf Factory Edition Specs:

Following is the technical details for the 2014 KTM 450SXF specifications with the most accurate facts and figures.

KTM 450 SX-F specs

Design 4-stroke engine, 1-cylinder, water-cooled
Displacement 449.3 cm³ or 27.418 cu inches
Bore 95 mm or 3.74 inches
Stroke 63.4 mm or 2.496 inches
Starting aid Plug-in meze (starter)
Gearbox 5-gear, scrabble budged
Engine lubrication Compression exchange lubrication with two pumps of Eaton
Primary transmission 32:76
Secondary gear ratio 14:50
Cooling Water cooled engine along with the stable transmission of coolant by water push
Clutch DDS Multidisc grip in oil bath/hydraulically stimulated
Ignition Contactless well-ordered by electronic ignition completely with digital ignition adjustment
Frame Frame for the Central tube is made of chrome molybdenum (steel tubing)
Fork Suspension of WP Up Side Down 4860 MXMA CC
Shock absorber Suspension  Of WP 5018 BAVP DCC
Suspension travel Front 300 mm or 11.81 inches
Suspension travel Rear 317 mm or 12.48 inches
Brake system Disc brakes with the brake calipers on the floating bearings
Brake discs – diameter Front 260 mm or 10.24 inches
Brake discs – diameter Rear 220 mm or 8.66 inches
Chain 5/8 x 1/4″
Steering head angle 63.5°
Wheelbase 1,495±10 mm or 58.86±0.39 inches
Ground clearance, unloaded 371 mm or 14.61 inches
Seat height, unloaded 992 mm or 39.06 inches
Total fuel tank capacity, approx. 7.5 l or 1.98 US gallons,Super unleaded (ROZ 95/RON 95/PON 91)
Weight without fuel, approx. 107.3 kg or 236.6 lb.



The bike KTM 450SXF is the bike enduring perfect engine with the flawless lubrication. It comprises of controlled braking system and fully grip on road. It provides it riders with an exciting pleasure that could be felt by riders during ride. The price estimated for this 2014 KTM 450SXF price is round about $10,000. Be the one to grab the bike first and enjoy the comforted and easy ride.
