Built for durability and crafted for exploration, the 2024 Harley-Davidson Pan-America Adventure Touring Bike is a rugged, two-wheeled multi-tool engineered to conquer various terrains. It transforms traditional touring into boundless adventure, making every road a discovery.
2024 Harley-Davidson Pan-America Adventure Touring Bike – Features and Specs
Revolution Max Engine
Producing 150 horsepower with a broad, flexible powerband, the Revolution Max engine enhances performance for both on-road and off-road riding.
Also Read: 2024 Harley-Davidson Ultra Limited Touring Bike Review
Ride Modes
The new 2024 Harley-Davidson Pan-America Adventure Touring Bike offers five pre-set ride modes—Sport, Road, Rain, Off-Road, and Off-Road Plus—and allows custom mode creation to suit your riding style.
H-D/Michelin Scorcher Tires
These tires, developed in partnership with Michelin, are designed to provide excellent grip and performance across various surfaces.
Also Read: 2024 Harley-Davidson Street Glide Touring Bike Review
2024 Harley-Davidson Pan-America Adventure Touring Bike – Technical Specifications
Dimensions
| Length | 2,270 mm |
| Seat Height, Unladen | low/high seat position; 850 mm/890 mm |
| Ground Clearance | 210 mm |
| Rake | 25 |
| Trail | 108 mm |
| Wheelbase | 1,585 mm |
| Tire, Type | Michelin Scorcher “Adventure”, Radial |
| Tires, Front Specification | 120/70R19 60V |
| Tires, Rear Specification | 170/60R17 72V |
| Fuel Capacity | 21.2 l |
| Oil Capacity (W/Filter) | 4.5 l |
| Weight, As Shipped | 229 kg |
| Weight, In Running Order | 245 kg |
2024 Harley-Davidson Pan-America Adventure Touring Bike – Engine
| Engine | Revolution Max 1250 |
| Bore | 105 mm |
| Stroke | 72.3 mm |
| Displacement | 1,252 cc |
| Compression Ratio | 13.0:1 |
| Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) |
| Exhaust | 2-into-1-into-1; catalyst in header |
Performance
| Engine torque testing method | EC 134/2014 |
| Engine Torque | 128 Nm |
| Engine Torque (RPM) | 6750 |
| Horsepower | 150 HP / 112 kW @ 8750 rpm |
| Lean Angle, Right (Deg.) | 42 |
| Lean Angle, Left (Deg.) | 42 |
| Fuel Economy | 5.5 l/100 km |
| CO2 Emissions Testing Method | EU 134/2014 |
| CO2 Emissions | 129 g/km CO2 |
Drive train
| Primary drive | Gear, 49/89 ratio |
| Gear Ratios (Overall) 1st | 13.11 |
| Gear Ratios (Overall) 2nd | 9.687 |
| Gear Ratios (Overall) 3rd | 7.509 |
| Gear Ratios (Overall) 4th | 6.057 |
| Gear Ratios (Overall) 5th | 5.08 |
| Gear Ratios (Overall) 6th | 4.436 |
Chassis
| Front fork | 47mm inverted fork with compression, rebound, & spring preload adjustability. Aluminum fork triple clamps. |
| Rear Shocks | Linkage-mounted, piggyback monoshock including compression, rebound, and hydraulic spring preload adjustability |
| Wheels, Front Type | Aluminum cast, satin black |
| Wheels, Rear Type | Aluminum cast, satin black |
| Brakes, Caliper Type | Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single-piston caliper |
| Brakes, Rotor Type | Front: dual rotor, floating, tower-mounted; Rear: solid uniform expansion rotor |
Electric
| Lights (As Per Country Regulation), Headlamp, Tail/Stop/Front Signal Lights | Daymaker Signature LED headlamp, low and high beam with signature position lighting; All LED Tail/Stop lamp with signature tail lighting; LED bullet turn signals |
| Gauges | 6.8 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, low temp alert, side stand down alert, TIP over alert, cruise, range, and tachometer indication BT capable – phone pairing to access phone calls, music, navigation (H-D App ONLY) |
Infotainment
| Screen size | 173 mm |
| Type | Color TFT |
| Headset Specifications (If Equipped) | Bluetooth |
| Languages | Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Polish, Korean, Norwegian, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish (Mexico/Spain), Swedish, Thai, Turkish, Vietnamese |
| Hands-Free Mobile Phone – Via Bluetooth | Standard |
| Voice Recognition Languages: Phone Functions Only | Phone dependent |
| Voice Recognition Languages: Tuner/Media/Navigation | Phone dependent |
| Rider/Passenger Intercom | The headset functions only |
| Vehicle Information Screen (Air Temperature, Oil Pressure, and EITMS) | Engine temp, Battery Voltage |
| Text-To-Speech (TTS) Languages | Phone dependent |
| USB | Charging and Instrument update, USB-C, 5V, 3A |
| Bluetooth | Phone/Media Supported |
Rider Safety Enhancements
| Anti-Lock Brake System (ABS) | Included |
| Electronic Linked Braking (ELB) | Included |
| Traction Control System (TCS) | Included |
| Drag-Torque Slip Control System (DSCS) | Included |
| Vehicle Hold Control (VHC) | Included |
| Wheel Lift Mitigation | Included |
| Cornering Enhanced Anti-Lock Brake System (C-ABS) | Included |
| Cornering Enhanced Electronic Linked Braking (C-ELB) | Included |
| Cornering Enhanced Traction Control System (C-TCS) | Included |
| Cornering Drag-Torque Slip Control System (C-DSCS) | Included |
| Enhanced Lift Mitigation | Included |
