The famous term “do-it-all” gets tossed around quite a bit, but there’s no denying its suitability and agility for describing the Honda CRF125F, a kind of midpoint in Honda’s CRF Trail lineup. Available in both standard and Big Wheel configurations, the 2024 Honda CRF125F Big Wheel Dirt Motorcycle is 50-state off-road legal, providing access to trails nationwide. It’s a confidence-inspiring, reliable, long-running machine that’s well-suited for young off-roaders, first-time trail riders, and creating enjoyable outings with friends and family.
Although small in the category, the 2024 Honda CRF125F Big Wheel Dirt Motorcycle shares the same styling and some of the features of its larger CRF brothers. All the rider has to do is hit the electric start, and the powerful air-cooled SOHC engine is eager to go. Explicitly tuned to deliver smooth bottom-end torque, it makes it perfect for junior riders. The diamond-spar steel frame features a 31 mm diameter telescopic fork with 140 mm of travel and a Honda Pro-Link rear suspension system, providing a rigid chassis to tackle rough terrain.
2024 Honda CRF125F Big Wheel Dirt Motorcycle – Features and Specs
Engine / Drivetrain
The new 2024 Honda CRF125F Big Wheel Dirt Motorcycle features a powerful 124.9cc SOHC engine offering smooth and linear power delivery. It features an electronically controlled Keihin fuel-injection system as a standard element. FI delivers linear and hesitation-free power for controlled delivery at all points in the power band. The brand-new four-speed gearbox is well matched to the broad power spread. An all-new electric starter makes getting going a breeze, with kick-start included as backup.
Also Read: 2024 Honda CRF110F Dirt Motorcycle Review
Chassis / Suspension
The new 2024 Honda CRF125F Big Wheel Dirt Motorcycle features a twin-spar steel frame with a heavy-duty design, inspired by the overall frame architecture of the famous CRF Performance Line. This design offers the perfect balance of rigidity and suppleness for trail-bike comfort.
The new 2024 Honda CRF125F Big Wheel Dirt Motorcycle features a 1-gallon steel fuel tank with an integrated fuel pump and fuel filter, providing a fuel carrying capacity. An added feature is a Low-Fuel indicator on the handlebars, which illuminates when 0.2 gallons of fuel remain. The overall frame design shields the tank in the event of a fall. The motorcycle features modern bodywork and graphics that complement the styling of the CRF Performance Line.
The brand-new Handlebar-mounted, multiple-function switch features a new starter button, an ignition “key on” indicator, a fuel-injection system status display, and a new low-fuel indicator light.
Also Read: 2024 Honda CRF50F Dirt Motorcycle Review
Additionally, half-waffle grips have a small circumference, providing a good fit for those with small hands.
The new 2024 Honda CRF125F Big Wheel Dirt Motorcycle features seat heights of 30.9 inches and wheel sizes of 19 inches in the front and 16 inches in the rear. The new front brake lever is adjustable to accommodate varying hand sizes, and the suspension system is backed by a 31mm fork, offering plush front-suspension action. An all-new Pro-Link rear suspension design with a sophisticated solo shock for better action.
The Smooth stopping power is provided by the hydraulic front brake, featuring a 220 mm rotor, and the 95 mm rear drum brake.
2024 Honda CRF125F Big Wheel Dirt Motorcycle – Price
The new 2024 Honda CRF125F Big Wheel Dirt Motorcycle is available for $3,799.
2024 Honda CRF125F Big Wheel Dirt Motorcycle – Technical Specifications
Engine
| Type | 124.9cc air-cooled 25º single-cylinder four-stroke |
| Valve Train | SOHC; 2 valves |
| Bore x Stroke | 52.4mm x 57.9mm |
| Compression Ratio | 9.0:1 |
| Induction | Fuel-injection system; 22mm throttle bore |
| Ignition | Full transistorised |
| Starter | Push-button electric starter/kick |
| Transmission | Constant-mesh 4-speed return; manual |
| Clutch | Multiplate wet |
| Final Drive | #420 chain; 13T/49T |
Suspension
| Front | 31mm conventional telescopic coil-spring fork; 6.7 in. stroke |
| Rear | Pro-Link system w/ single shock; 6.6 in. travel |
Brakes
| Front | Hydraulic; single 220mm disc |
| Rear | Mechanical 95mm leading-trail drum |
Tires
| Front | 70/100-19 w/ tube |
| Rear | 90/100-16 w/ tube |
Measurements
| Rake (Caster Angle) | 27.5° |
| Trail | 94mm |
| Length | 73.1 in. |
| Width | 30.3 in. |
| Height | 42.1 in. |
| Ground Clearance | 10.3 in. |
| Seat Height | 30.9 in. |
| Wheelbase | 49.4 in. |
| Fuel Capacity | 1.0 gal. |
| Curb Weight | 199 lbs. |
Other
| Color | Red |
