2022 Harley-Davidson Sportster S Cruisers Review Specs Price

0
225
2022 Harley-Davidson Sportster S Cruisers

The exhilaration of dynamic acceleration, whereby exceptional power is unleashed, lies at the heart of the 2022 Harley-Davidson Sportster S Cruisers intended riding experience, moderated by stealthy technology. Torque on demand provides an uncompromising, exciting burst of push and exhilaration at any given moment, whether at a stoplight or around a corner.

The release of Sportster S marks the beginning of a brand new volume in the Sportster tale. A brand first established in 1957 that blew away the competition has been reborn to destroy today’s benchmarks.

2022 Harley-Davidson Sportster S Cruisers – Features and Specs

2022 Harley-Davidson Sportster S Cruisers

Powertrain

There has been a long history of iconic V-Twin motorcycles, and now the next chapter is here. The Revolution Max’s powertrain is a liquid-cooled, double-overhead-camshaft V4 with variable valve timing that provides a wide range of torque and an instantaneous power band tailored to the rider’s needs.

High Mount Exhaust

The new pipes are corrosion-resistant 304-series stainless steel and are designed primarily to deflect exhaust heat away from the rider’s legs and tail section, evoking the glory days of H-D flat-track racing.

Instrumentation

Classic Meets Modern: 4” Round Display

Digital gauges, ride modes, indicators, and turn-by-turn navigation including the Harley-Davidson app, are all housed in a 4″ round thin-film transistor LCD that connects via Bluetooth. There are buttons on both sides of the controls that allow you to access all of the features.

Choose Your Ride Mode

You can tune your motorcycle with a unique combination of power distribution, engine braking, Cornering Enhanced Antilock Braking System, and Cornering Enhanced Traction Control System (C-TCS) settings by toggling between three pre-programmed Ride Modes (Sport, Road, and Rain).

2022 Harley-Davidson Sportster S Cruisers

Dual Purpose Powertrain

To reduce overall weight and keep handling precise, the Revolution Max 1250T is integrated into the motorcycle’s chassis. Thanks to a low center of gravity and a very rigid chassis, the performance is palpable.

Performance and Capability

With the new Cornering Enhanced Traction Control System that interferes based on the calculated available traction, the Sportster S has some of the most advanced and safest engine-control electronics of any Sportster. In addition, it has three different power delivery profiles that can be set up beforehand and a fourth that the rider can customize.

For propulsion, there is a Revolution Max 1250T engine, which, while still V-twin, does so at a wider angle than the standard 45 degrees, making it immediately apparent that this is not your grandfather’s Sportster. The liquid-cooled mill is already a technological and aesthetic head-turner, so there’s no need to draw attention to it. In a non-standard departure, the engine has a bore of 105 mm and a stroke of 72.3 mm, a ratio that allows for high RPM and impressive performance.

The variable valve timing and dual overhead cams are novel features that produce a broader and more manageable power band. That’s right, this H-D has a stated horsepower rating, and we can’t say we blame them. This engine has a lot to be proud of, what with its 121 horsepower and 94 pounds of torque, which peak at 6,000 rpm but are usable for the majority of the rev range.

The final drive is a carbon-reinforced belt and pulley, and in yet another departure from the norm, the motorcycle is mounted on the rider’s left side. The Sportster S, with its six-speed transmission and a maximum speed of 120.7 mph, is fast enough to be dangerous on public roads.

2022 Harley-Davidson Sportster S Cruisers

Design

The design of the new Sportster S was influenced by the factory’s previous V-Rod models, which have since been discontinued. That was a broad allusion to the fact that the engineers’ demeanor is consistent despite their arrival via two very different methods.

It’s worth noting that the Bronx, who was supposed to use the same engine and be promoted as a nude Euro/Asian street fighter, met an untimely end. This new proper sport cruiser is competing for a different segment of the market. However, it may still attract some of the same types of buyers or at least offer an alternative to the details above.

The letter “S” provides a refreshing fusion of modern and traditional elements. While the inverted forks and rounded-off rectangle of the LED headlight nod to modernity, the fat tires, cut-down fenders, and general blackout treatment are all hallmarks of the old-school custom style that has long distinguished the breed. Every bulb is an LED, so you’ll have excellent vision in every direction.

The whole front end is painted black, right down to the short-rise handlebar and bar-end mirrors, and the same treatment continues behind the bike. The circular, four-inch instrument panel may look retro. Still, its contemporary, full-color TFT display combines standard gauges with settings for the vehicle’s technology and the ride’s comfort.

Even if your vehicle isn’t fitted with an Infotainment system, you can still use your phone to play music, take calls, and obtain turn-by-turn directions. You’ll need the Harley-Davidson app, a Bluetooth-enabled helmet, and a headset to use this feature.

Although the fuel tank has its signature teardrop form known to Sportster family riders, the bike’s profile soon tapers down below the single seat in an aerodynamically sensible manner. The remainder of the rear equipment is attached to the hugger in a sport bike-like fashion, which keeps the tail tidy and sleek despite the addition of additional cutting-edge LED technology.

Chassis

The Sportster S is a prime example of H-transition D’s to stressed-engine designs. Its front and rear tubular steel frame portions attach to the transmission, removing the need for most of the tube and significantly cutting down on weight. What comes out of this is a highly rigid chassis, which helps with handling precision. It’s a brand new addition to The MoCo, although the frame is ubiquitous elsewhere.

With a rake of 30 degrees and a trail of 5.8 inches, the “S” will be relatively stable at high speeds, even while encountering crosswinds and navigating pressure waves from oncoming traffic. H-D stays true to its roots by not altering the steering geometry to increase maneuverability. It would appear that good talent is sufficient.

If you weigh at least 180 pounds, you’ll be able to squat down to the appropriate height using a seat 28.9 inches off the deck. Dunlop Harley-Davidson Series radials measuring 160/70-17 up front and 180/70-16 in the rear are mounted on cast wheels.

Using tubular parts for the frame and concealing the fully-adjustable piggyback monoshock beneath the hood gives the swing arm a very sport bike-like appearance, which is something unique for a Sportster. The front end is suspended by 43 mm inverted forks on a trinity of suspension adjustments.

2022 Harley-Davidson Sportster S Cruisers

The brakes are a four-bore caliper biting a 320 mm front disc and a 260 mm disc and single-piston anchor in the back. Still, the real star is the Cornering-Enhanced Anti-lock Braking System that is standard equipment and puts the notoriously staid Motor Company on electronic par with the market’s most sporty vehicles.

2022 Harley-Davidson Sportster S Cruisers – Price

Harley-Davidson continued its habit of including the cost of paint in the final price tag. An entry-level Vivid Black bundle may be purchased for $15,499 in this first look. You can add $400 to your initial investment if you decide that White Sand Pearl or Mineral Green Metallic are more your speed.

Harley Davidson Sportster S vs Indian FTR

Right on the heels of a historic season in Flat Track Racing, the FTR is a street-legal version of the now-iconic race bike, sharing much of its design and layout with its racing counterpart. The rider’s triangle is also different, with the sport bike-style jockey foot pegs being the antithesis of the foot-forward Sportster S.

In terms of performance, there is little to opt between the two; the Indian V-Twin produces 120 horsepower and 87 pound-feet of torque, while the Harley-Davidson produces 120.1 horsepower and 94.0 foot-pounds of torque. All of them have fully adjustable suspension, but it appears that Indian ABS is the essential kind, and there are no advanced electronics.

Indian’s decision to sell its entry-level FTR for $12,999 (MSRP) leaves a couple of grand on the table, but if you’re into the gimmicks, H-D is your only option.

2022 Harley-Davidson Sportster S Cruisers – Technical Specifications

Dimensions

Length 89.4 in. (2,270 mm)
Overall Width 33.1 in. (840 mm)
Overall Height 42.7 in. (1,085 mm)
Seat Height, Laden 28.9 in. (734 mm)
Seat Height, Unladen 30.1 in. (765 mm)
Static Ground Clearance 3.5 in. (90 mm)
Rake (steering head) (deg) 30
Fork Angle (deg) 28
Trail 5.8 in. (148 mm)
Wheelbase 59.8 in. (1,520 mm)
Tires, Type Dunlop Harley-Davidson Series, radial
Tires, Front Model GT503
Tires, Front Specification 160/70R17 73V
Tires, Rear Model GT503
Tires, Rear Specification 180/70R16 77V
Fuel Capacity 3.1 gal. (11.8 l)
Reserve Fuel Capacity, Fuel Injection (warning light) 0.8 gal. (3 l)
Oil Capacity (w/filter) 4.75 qt. (4.5 l)
Transmission Capacity N/A
Primary Chain Case Capacity N/A
Coolant Capacity 2.32 qt. (2.2 l)
Weight, As Shipped 487 lb. (221 kg)
Weight, In Running Order 502 lb. (228 kg)
Gross Vehicle Weight Rating 922 lb. (418 kg)
Gross Axle Weight Rating, Front 359 lb. (163 kg)
Gross Axle Weight Rating, Rear 595 lb. (270 kg)
Luggage Capacity -Volume N/A
2022 Harley-Davidson Sportster S Cruisers
2021 Sportster S – Scotland Photo Shoot

Engine

Engine Revolution Max 1250T
Valves Chain-driven, DOHC, hydraulic self-adjusting lifters, intake and exhaust VVT; four valves per cylinder
Bore 4.134 in. (105 mm)
Stroke 2.846 in. (72.3 mm)
Displacement 76.4 cu in (1,252 cc)
Compression Ratio 12.0:1
Fuel System All-new Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Downdraft intake, tuned velocity stacks, and washable filter media
Exhaust 2-into-1-into-2, catalyst in the muffler
Lubrication System Semi-Dry Sump

Drivetrain

Primary Drive Gear, 49/89 ratio
Final Drive Belt, 34/80 ratio
Clutch Mechanical, eight plates wet, assist & slip, 1090N
Transmission 6-speed
Gear Ratios (overall) 1st 12.21
Gear Ratios (overall) 2nd 9.022
Gear Ratios (overall) 3rd 6.994
Gear Ratios (overall) 4th 5.641
Gear Ratios (overall) 5th 4.731
Gear Ratios (overall) 6th 4.131

Chassis



Frame All-new Stressed-member, high strength low alloy steel trellis frame; MIG welded; stamped, cast, and forged junctions; aluminum forged mid-structure
Swingarm High strength low alloy steel, tubular sections, forged axle junctions; stamped x-member, MIG welded
Front Fork 43mm of inverted fork including compression, rebound, and spring preload adjustability. Aluminum fork triple clamps.
Rear Shocks Linkage-mounted, piggyback mono-shock with compression, rebound, and hydraulic spring preload adjustability
Wheels, Optional Style Type N/A
Wheels, Front Type Aluminum cast, satin black
Wheels, Front Width 4.5 in. (114 mm)
Wheels, Front Height 17 in. (432 mm)
Wheels, Rear Type Aluminum cast, satin black
Wheels, Rear Width Five in. (127 mm)
Wheels, Rear Height 16 in. (406 mm)
Brakes, Caliper Type Front: radially mounted, monoblock, 4-piston caliper Rear: floating, single-piston caliper
Brakes, Rotor Type Front: single rotor, floating, tower-mounted Rear: solid uniform expansion rotor
Brakes, Front Diameter 12.6 in. (320 mm)
Brakes, Front Thickness 0.2 in. (6 mm)
Brakes, Front is dual No
Brakes, Rear Diameter 10.2 in. (260 mm)
Brakes, Rear Thickness 0.2 in. (5 mm)
Front brake lever free travel N/A
Rear brake pedal free travel N/A
Brakes, Anti-Lock Braking System (ABS) Standard
Suspension Travel, Front 3.6 in. (92 mm)
Suspension Travel, Rear Two in. (51 mm)

Performance

Engine Torque Testing Method J1349
Engine Torque 94 ft-lb (127 Nm)
Engine Torque (rpm) 6,000
Power (Hp/kW) 121 HP / 90 kW @ 7500 rpm
Lean Angle Testing Method J1168
Lean Angle, Right (deg.) 34
Lean Angle, Left (deg.) 34
Maximum hill-starting ability N/A
Fuel Economy Testing Method Estimated City/Hwy
Fuel Economy 49 mpg (4.8 l/100 km)
CO₂ Emissions Testing Method N/A
CO₂ Emissions N/A

Electric

Battery Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 12Ah, 225 CCA at 0°F
Charging Three-phase, 45 Amp system (300 Watts @13 Volts, 1200 rpm, 585 Watts max power @ 13 Volts, 2250 rpm)
Starting 0.9 kW electric with direct drive starter motor engagement
Lights (as per country regulation), Headlamp All LED headlamps, low and high beams with signature position lighting
Lights (as per country regulation), Tail/Stop All LED Tail/Stop lamps with signature tail lighting
Lights (as per country regulation), Front Signal Lights LED Bullet Turn Signals
Lights, Rear Turn Signals LED Bullet Turn Signals
Gauges 4-inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over attention, cruise, range, and tachometer indication BT capable – phone pairing to access phone calls, music, navigation (H-D App ONLY)
Auxiliary Lamps N/A
Electric Power Outlet USB C-Type, Output 5V at 2.4 Amp
GPS System N/A
Reverse Gear N/A

Warranty And Service

Warranty 24 months (unlimited mileage)
Service Interval First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) after that
