Purpose-built for the most demanding on- and off-road adventures, the 2024 Harley-Davidson Pan-America Special Adventure Touring Bike redefines the adventure touring experience. This model is Harley-Davidson’s ultimate exploration machine—brutal, tech-savvy, and thrilling to ride. Packed with exclusive features, it includes adaptive suspension and cutting-edge ride technology to boost performance, safety, and confidence.
The Adaptive Ride Height (ARH) system is an industry-first innovation that automatically adjusts between low-stopped and ideal ride heights while in motion, offering comfort without compromising ground clearance.
2024 Harley-Davidson Pan-America Special Adventure Touring Bike – Features
Revolution Max Engine
With 150 horsepower and an adaptable powerband, this engine ensures thrilling performance across all environments.
Adaptive Suspension
ARH lowers seat height when stationary and automatically maintains optimal suspension sag by continuously adjusting preload.
Also Read: 2024 Harley-Davidson Pan-America Adventure Touring Bike Review
Ride Modes
Choose from five preset ride modes—Sport, Road, Rain, Off-Road, and Off-Road Plus—or configure a custom setup tailored to your preferences.
2024 Harley-Davidson Pan-America Special Adventure Touring Bike – Price
The new 2024 Harley-Davidson Pan-America Special Adventure Touring Bike is available at $19,999 only.
2024 Harley-Davidson Pan-America Special Adventure Touring Bike – Technical Specifications
Dimensions
| Length | 89.4 in. |
| Seat Height, Laden | low/high seat position; 31.1 in./32 in. |
| Ground Clearance | 6.9 in. |
| Rake | 25 |
| Trail | 4.3 in. |
| Wheelbase | 62.4 in. |
| Tire, Type | Michelin Scorcher “Adventure”, Radial |
| Tires, Front Specification | 120/70R19 60V |
| Tires, Rear Specification | 170/60R17 72V |
| Fuel Capacity | 5.6 gal. |
| Oil Capacity (W/Filter) | 4.75 qt. |
| Weight, As Shipped | 534 lb. |
| Weight, In Running Order | 569 lb. |
Engine
| Engine | Revolution Max 1250 |
| Bore | 4.134 in. |
| Stroke | 2.846 in. |
| Displacement | 76.4 cu in |
| Compression Ratio | 13.0:1 |
| Fuel System | Electronic Sequential Port Fuel Injection (ESPFI) |
| Exhaust | 2-into-1-into-1; catalyst in header |
Performance
| Engine torque testing method | J1349 |
| Engine Torque | 95 ft-lb |
| Engine Torque (RPM) | 6750 |
| Horsepower | 150 HP / 112 kW @ 8750 rpm |
| Lean Angle, Right (DEG.) | 42 |
| Lean Angle, Left (DEG.) | 42 |
| Fuel Economy Testing Method | Estimated City/Hwy |
| Fuel Economy | 46 mpg |
Drive train
| Primary drive | Gear, 49/89 ratio |
| Gear Ratios (Overall) 1st | 13.11 |
| Gear Ratios (Overall) 2nd | 9.687 |
| Gear Ratios (Overall) 3rd | 7.509 |
| Gear Ratios (Overall) 4th | 6.057 |
| Gear Ratios (Overall) 5th | 5.08 |
| Gear Ratios (Overall) 6th | 4.436 |
Chassis
| Front Fork | 47 mm inverted fork including electronically adjustable semi-active damping control. Aluminum fork triple clamps |
| Rear Shocks | Linkage-mounted monoshock including automatic electronic preload control and semi-active compression & rebound damping |
| Wheels, Optional Style Type | Anodized aluminum tubeless laced |
| Wheels, Front Type | Aluminum cast, satin black |
| Wheels, Rear Type | Aluminum cast, satin black |
| Brakes, Caliper Type | Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single-piston caliper |
| Brakes, Rotor Type | Front: dual rotor, floating, tower-mounted; Rear: solid uniform expansion rotor |
Electric
| Lights (as per country regulation), Headlamp, Tail/Stop/Front Signal Lights | Daymaker Adaptive LED Headlamp with 6-segment LED banking lamp; All LED Tail/Stop lamp with signature tail lighting; LED bullet turn signals |
| Gauges | 6.8 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable – phone pairing to access phone calls, music, navigation (H-D App ONLY) |
Infotainment
| Screen Size | 6.8 in |
| Type | Color TFT w/ Touch |
| Headset Specifications (If Equipped) | Bluetooth |
| Languages | Arabic, Chinese (Simplified/Traditional), Czech, Danish, Dutch, English (default), Finnish, French (Canada/France), German, Greek, Hungarian, Italian, Japanese, Polish, Korean, Norwegian, Portuguese (Portugal/Brazil), Indonesian, Russian, Slovak, Spanish (Mexico/Spain), Swedish, Thai, Turkish, Vietnamese |
| Hands-Free Mobile Phone – Via Bluetooth | Standard |
| Voice Recognition Languages: Phone Functions Only | Phone dependent |
| Voice Recognition Languages: Tuner/Media/Navigation | Phone dependent |
| Rider/Passenger Intercom | The headset functions only |
| Vehicle Information Screen (Air Temperature, Oil Pressure, and EITMS) | TPMS, Engine temp, Battery Voltage, Ambient Air Temp |
| Text-To-Speech (TTS) Languages | Phone dependent |
| USB | Charging and Instrument update, USB-C, 5V, 3A |
| Bluetooth | Phone/Media Supported |
Rider Safety Enhancements
| Anti-Lock Brake System (ABS) | Included |
| Electronic Linked Braking (ELB) | Included |
| Traction Control System (TCS) | Included |
| Drag-Torque Slip Control System (DSCS) | Included |
| Vehicle Hold Control (VHC) | Included |
| Tire Pressure Monitoring System (TPMS) | Included |
| Wheel Lift Mitigation | Included |
| Cornering Enhanced Anti-Lock Brake System (C-ABS) | Included |
| Cornering Enhanced Electronic Linked Braking (C-ELB) | Included |
| Cornering Enhanced Traction Control System (C-TCS) | Included |
| Cornering Drag-Torque Slip Control System (C-DSCS) | Included |
| Enhanced Lift Mitigation | Included |
