2019 Benelli TRK 502 Adventure Bike Review Specs

Benelli is always one of the best and most demanding motorcycle manufacturing brand. Its 2019 Benelli TRK 502 Adventure Bike is considered to be the best motorcycle of all time. The adventure motorcycle contains a high-quality suspension that includes the 50 mm inverted fork up front, including 135 mm of stroke and swingarm-mono-shock system in the rear.

The combination offers superb wheel control and comfortable ride on and off-road. This bike is the best combination of stylish looks and high performing engine. The review of 2019 Benelli TRK 502 Adventure Bike with its specifications are given below.

2019 Benelli TRK 502 Adventure Bike – Features and Specifications

2019 Benelli TRK 502 Adventure Bike

Engine Features

The 2019 Benelli TRK 502 Adventure Bike and 2019 Benelli TRK 502 X comes with the powerful DOHC 499.6 ccm twin-cylinder and four-stroke engine. It can quickly deliver the power of 47.6 HP at 8500 RPM and torque of 45 Nm at 5000 RPM. The bore to stroke ratios of 69 mm and 66.8 mm respectively have been employed along with the compression ratio of 11.5:1 better than 2019 Benelli TRK 251.

The liquid cooling system has been used that efficiently maintains the overall temperature. An all-new electric starter makes the overall starting much easy and full of confidence. The six-speed gearbox provides an ultimate gear shifting experience of all times. The engine fully complies with the strict Euro 4 standards.

2019 Benelli TRK 502 Adventure Bike

Chassis Features

This Adventure Benelli bike contains the sturdy Trestle in steel tubes, offering maximum stability throughout the ride. The 2019 Benelli TRK 502 Adventure Bike comes in an attractive White Orange Black. The suspension system comprises up of a front suspension of an adjustable upside-down fork of 50 mm and a rear suspension containing rear swingarm with central shock absorber spring preload-adjustable.

The braking system includes the double-disc with four-piston, including ABS, while the rear brakes have the single disc with single-piston calipers with ABS. The aluminum alloy wheel has been used on the bike.

2019 Benelli TRK 502 Adventure Bike

2019 Benelli TRK 502 Adventure Bike – Technical Specifications

Engine and transmission

Displacement 499.6 ccm (30.49 cubic inches)
Engine type Twin, four-stroke
Power 47.60 HP at 8500 RPM
Torque 45 Nm at 5000 RPM
Compression 11.5:1
Bore x stroke 69 mm x 66.8 mm (2.7inches x 2.6inches)
Valve-per-cylinder 4
Fuel system Injection
Fuel control Double Overhead Cams/Twin Cam (DOHC)
Ignition TLI
Lubrication system Wet sump
Cooling system Liquid
Gearbox 6-speed
Transmission type,final drive Chain
Clutch Wet
Fuel consumption 3.9 liters/100 km (25.6 km/l or 60.31 mpg)
Greenhouse gases 90.5 CO2 g/km. (CO2 – Carbon dioxide emission)
Emission details Euro 4. Catalytic converter and oxygen sensors.

2019 Benelli TRK 502 Adventure Bike Specs

Chassis, suspension, brakes, and wheels

Frame type Trestle in steel tubes
Front suspension Adjustable Upside-down forks 50 mm
Front-wheel travel 135 mm (5.3 inches)
Rear suspension Rear swing arm including central shock absorber spring preload-adjustable
Rear-wheel travel 45 mm (1.8 inches)
Front tire 120/70-ZR17
Rear tire 160/60-ZR17
Front brakes Double disc. 4-piston, ABS
Front brakes diameter 320 mm (12.6 inches)
Rear brakes Single disc. Single piston caliper, ABS
Rear brakes diameter 260 mm (10.2 inches)
Wheels Aluminum alloy (optional aluminum rim spoked )

2019 Benelli TRK 502 Adventure Bike Specs

Physical measures and capacities

Dry weight 213.0 kg (469.6 pounds)
Power/weight ratio 0.2235 HP/kg
Seat height 800 mm (31.5 inches)
Alternate seat height 825 mm (32.5 inches)
Overall height 1,235 mm (48.6 inches)
Overall length 2,170 mm (85.4 inches)
Overall width 912 mm (35.9 inches)
Ground clearance 190 mm (7.5 inches)
Wheelbase 1,525 mm (60.0 inches)
Fuel capacity 20 liters (5.28 gallons)

2019 Benelli TRK 502 Adventure Bike Specs

Other specifications

Color options White, orange, black
Starter Electric

2019 Benelli TRK 502 Adventure Bike


In conclusion, Bikes Catalog would love to say that the 2019 Benelli TRK 502 Adventure Bike is one of the best and high performing bike that not only provides the best performance but gives awesome riding pleasure. The careful design seat provides a superb seating position and best handling experience of all times. Those who prefer riding adventure bikes on all kinds of terrain should prefer 2019 Benelli TRK 502 and have a lovely ride.
