2017 Yamaha XSR900 Sports Heritage Bike Specs Review

The Yamaha Brand is always manufacturing the different variety of bikes to meet the demand of various customers. Yamaha Brand, being one of the Most Bike Selling Brand in the World is manufacturing the quality bikes. The new 2017 Yamaha XSR900 Sports Heritage Bike is one of the best models of Yamaha. It has sporty look with the heritage design. Like the 2017 Yamaha SR400, it is a sports heritage bike but has a powerful engine. The engine gives thrilling power and authentic performance. The seat offers an incredibly comfortable ride. The fuel tank is very prominent and has great fuel capacity for long rides. The quality components of this bike give the impressive ride. The review of new 2017 Yamaha XSR900 Sports Heritage Bike is written below.

2017 Yamaha XSR900 Sport Heritage Bike

2017 Yamaha XSR900 Sports Heritage Bike – Specification and Price


The new 2017 Yamaha XSR900 Sports Heritage Bike features the thrilling engine of 847cc. It is a liquid-cooled inline 3-cylinder, DOHC, 4-valve-per-cylinder Cross-plane Crankshaft Concept engine based on an FZ-09. This engine features the compression ratio of 11.5:1 and bore and stroke of 78mm x 59.1mm. The compact motor gives the torque and quicker revving character of the engine. This new bike is equipped with the Yamaha’s Chip Controlled Throttle (YCC-T) for accurate throttle control. The Yamaha’s selectable D-MODE allows the rider to adjust the engine character on the fly. There is also STD Mode, which is used to set the bike to accommodate the wide range of riding conditions. A Mode delivers the sportier throttle response in the low-to-mid-rpm range while the B Mode allows the rider to enjoy the softer throttle response. The Traction Control System allows the rider to gain more confidence by regulating its ignition timing, fuel injection and the opening of the throttle valve based on the speed of the wheel. There are three available modes: “Mode 1” is used for minimal intervention, “Mode 2” is for maximum intervention and an “OFF Mode” switches off the entire system. The motor uses the geared counter balancer that revolves in the opposite direction as a crankshaft to keep the vibration at the minimum level and for the smooth ride. Just like the super sports models, the new 2017 Yamaha XSR900 Sports Heritage Bike contains the fracture split connecting rods for ultimate performance. The fracture-split method splits the big-end ring of a connecting rod in the two by applying the sharp impact to create a perfect matching surface when it is bolted around a crankshaft. The intake funnels of the engine have been designed with the three uneven lengths just to achieve the potent mid-range torque and unique intake sound. This design is combined with the YCC-T system to give an ideal thrust for street riding. This motorcycle uses the 6-speed transmission that takes full advantage of the low-to-mid-range torque and an excellent response of an inline triple while enhancing the narrow 3-cylinder design. The new 2017 Yamaha XSR900 Sports Heritage Bike features an advanced assist-and-slipper clutch unit for greater clamping force and back-torque reduction. It uses the lighter clutch springs to reduce the clutch lever effort by 20 % plus to minimize the rear-wheel hop under an aggressive deceleration.

2017 Yamaha XSR900 Sports Heritage Bike

Chassis/ Suspension

The new 2017 Yamaha XSR900 Sports Heritage Bike features the world-class engineering with a standout neo-retro style. This is a new type of machine for those riders who are looking for an authentic and honest bike with excellent performance. This bike features exposed aluminum details, retro-influenced bodywork, stepped seat and a custom lighting and instrumentation. The new bodywork features the new aluminum frame containing the sport-oriented wheelbase with rake and trail geometry working with a compact engine of 3-cylinder to achieve the light handling. This bike features the new suspension system with the spring preload and a rebound damping adjustments for the truly customizable ride. It features an inverted fork with the inner tubes of 41 mm offering the travel of 5.4 inches. The rear linkage-type mono-shock uses the horizontal layout for improved mass centralization along with the rear wheel travel of 5.1 inches. This bike features an exceptional braking power due to its sportbike-spec front brakes. It consists up of paired floating 298 mm of discs with the radially mounted 4-piston calipers and the rear disc of 245 mm. The new ABS works to prevent the wheel lock under the hard deceleration. The lightweight 10-spokes cast aluminum wheels are fitted with the front tire of 120/70ZR17 and a rear tire of 180/55ZR17 for maximum traction.

2017 Yamaha XSR900 Sports Heritage Bike

Additional Features

The new 2017 Yamaha XSR900 Sports Heritage Bike features the round LCD panel that shows plenty of useful information about digital tachometer, gear position, speedometer, eco mode indicator and much more. The up front, larger, round multi-reflector headlight features both style and illumination in equal measure. The new round all-LED tail and brake light are mounted above the rear fender provide amazing look. This bike features the compact 3.7 gallons of the fuel tank. It is beautifully shaped and hand-finished with aluminum covers for best design. It features the wide and tapered aluminum handlebar, dished saddle and a forged aluminum foot controls offers the comfortable upright riding position. This Yamaha Bike has the best details features the single-piece stepped saddle with the XSR900 logo. The mirrors are classic teardrop shapes with an excellent rearward visibility. The new compact radiator has exposed aluminum covers. The front fender uses the retro-influence aluminum stays.

Unique Keys Features

  • A Style All Its Own.
  • Advanced Crossplane Crankshaft Concept Engine.
  • Cutting-Edge Electronics.
  • Powerful Braking with ABS.
  • Compact, Sporty Chassis.

2017 Yamaha XSR900 Sports Heritage Bike – Price

The new 2017 Yamaha XSR900 Sports Heritage Bike is available from February 2017 in Titanium Blue color with the price of $9,499 only.

2017 Yamaha XSR900 Sports Heritage Bike

2017 Yamaha XSR900 Sports Heritage Bike – Specs


Engine Type 847 cc liquid-cooled DOHC inline 3-cylinder 4- stroke; 12 valves
Bore x Stroke 78.0 mm x 59.1 mm
Compression Ratio 11.5:1
Fuel Delivery Yamaha Fuel Injection with YCC-T
Ignition TCI: Transistor Controlled Ignition
Transmission 6-speed; multiple assist-and-slipper wet clutches
Final Drive Chain

2017 Yamaha XSR900 Sports Heritage Bike Specs


Suspension / Front 41 mm inverted fork, adjustable preload and rebound damping; 5.4 inches travel
Suspension / Rear Single shock, adjustable preload, and rebound damping; 5.1 inches travel
Brakes / Front Dual 298 mm discs; ABS
Brakes / Rear 245 mm disc; ABS
Tires / Front 120/70ZR17
Tires / Rear 180/55ZR17

2017 Yamaha XSR900 Sports Heritage Bike Specs


L x W x H 81.7 inches x 32.1 inches x 44.9 inches
Seat Height 32.7 inches
Wheelbase 56.7 inches
Rake (Caster Angle) 25.0°
Trail 4.1 inches
Maximum Ground Clearance 5.3 inches
Fuel Capacity 3.7 gallons
Fuel Economy 44 mpg
Wet Weight 430 lb

2017 Yamaha XSR900 Sports Heritage Bike Specs


Warranty 1 Year (Limited Factory Warranty)

2017 Yamaha XSR900 Sports Heritage Bike


This article is about the new 2017 Yamaha XSR900 Sports Heritage Bike by Yamaha Brand and it is covered under www.bikescatalog.com. It is an amazing sports bike with the best heritage look. The stylish body and excellent finishing of the bike always demand for the second look. The incredible looking fuel tank provides enough fuel capacity to ride in a city traffic. The powerful engine gives amazing riding experience. Each part is optimized to achieve the most of this bike. So don’t wait too long and purchase this bike.
