Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV

It’s a sport-utility quad with striking style and more excellent capability and durability than ever before from Suzuki, the company that invented the 4-wheel ATV. The renowned Suzuki King Quad’s legacy is alive and well, and it’s waiting for you to join it. Every model is simple to ride and has features that no other brand can match.

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV – Features

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV

Key Features

Low-effort electronic power steering, aggressive appearance, and cast aluminum wheels round out the package. Excellent payload, excellent ride quality on any terrain, and plenty of towing capability make this a no-brainer of a vehicle.QuadmaticTM gearbox with engine braking and a powerful EFI-fed engine. LED headlights, fenders, handlebars, and a complete LCD instrument panel. You may customize your King Quad with various accessories to meet your specific needs.

Engine Features

Powerful low-to-mid-range torque and excellent peak power are delivered by the 722cc DOHC, single-cylinder, liquid-cooled, four-stroke engine’s tuning. As a result of the engine’s large oil pump, the piston oil jet system receives a steady supply of cooking oil. To achieve and maintain a low center of gravity and hence a lower center of gravity for the driver and passengers, the engine and head are canted forward. Water and dirt are kept out of the air intake by a high-mount design. The massive 36mm intake valves and straight ports on the four-valve cylinder head provide excellent cylinder charging efficiency.

A small cylinder head is made possible by the chain-and-gear camshaft drive arrangement used in Quad Bike. The SCEM coating on a lightweight aluminum cylinder offers outstanding heat transmission and ring sealing, resulting in a very efficient combustion chamber. To provide a smooth ride, the engine is equipped with two balancer shafts. In addition to offering outstanding throttle response and fuel economy, Suzuki’s Advanced Fuel Injection provides consistent power across the broad rpm range. It improves the starting of the engine in any weather. King Quad models that meet California’s strict evaporative emissions standards, for example, have no problem meeting US emissions regulations. An aluminum radiator with an overall diameter thermostatically-controlled cooling fan maintains a consistent engine operating temperature.

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV

Transmission Features

With a fender-attached gate-type shifter for high/low range options, the QuadmaticTM CVT-type automatic gearbox offers flexibility and simplicity. When the throttle is off, the ATV’s innovative engine braking system helps keep it in control on steep descents. CVT spring and weight tuning delivers smooth and forceful acceleration from a stop and balances the engine’s performance with the chassis’ high towing capacity. Controlled engine braking provided by the CVT tune increases downhill rider confidence and comfort. Torque-sensing limited-slip front differential gives powerful traction while maintaining a light steering feel. 4WD traction is significantly enhanced with a differential-lock system. It is straightforward to switch between 2WD, 4WD, and differential-lock 4WD, thanks to handlebar-mounted pushbutton controls. When removing the bike from mud, an override button on the left handlebar may be used to bypass the standard speed limits.

Chassis Features

High-clearance fenders on the outstanding, angular bodywork keep the rider safe from flying debris. The body panels were meant to make routine maintenance tasks, such as checking oil levels and replacing air and fuel filters easier. Enhanced rider comfort, simplicity of use, and towing capacity are all facilitated by the King Quad’s structure, which has thick-wall tubes and strengthened brackets in crucial sections. Low effort and tighter turning are accomplished by tuning the essential steering features to an “under-steer” situation. It makes it possible to employ handlebars that are taller and more comfortable.

Electric power steering on the King Quad is more potent than ever, reducing steering effort and minimizing vibration and jolts for the rider. Large-diameter gas-charged shock absorbers including five-way spring preload adjustment, are part of an independent double A-arm front suspension with 6.7 inches of wheel travel. An A/I beam rear suspension with 7.7 inches of wheel travel has a big diameter and gas-charged shock absorbers that can be preloaded in five ways. Shocks to the rider may be reduced by using a big rear stabilizer bar with a compliant bushing. High-friction braking pads, lever ratio and fluid lines all work together to provide the best possible braking performance. An all-new foot lever ratio of the sealed, multi-plate rear braking system gives outstanding rider control.

High longevity, reduced unsprung weight, and inexpensive maintenance result from the rear brake’s clutch-type construction. Comfortable T-shape seats from Suzuki let the rider move freely while traversing challenging terrain. Polyethylene skid plates defend against debris, rocks and rugged terrain while requiring little effort to cross them. All-new sturdy plastic shields protect the front and rear half shafts. Cast aluminum wheels with machined spoke and rim edges and high-traction 25-inch Carlisle tires are placed on lightweight, powder-coated black cast-aluminum wheels.

Utility/ Convenience Features

Headlights fitted to all-new handlebars of the Suzuki 2020 King Quad 750AXi Power Steering SE Utility Quad Bike illuminate the path in the direction of travel. The King Quad’s unique bodywork includes dual 35-watt headlights (with high- and low-beam settings). With its attractive low-draw and brilliant LED tail light, the quad bike can be easily seen even at night. With the Suzuki King Quad’s substantial towing capability, a receiver-style trailer hitch installation makes it simple and easy to pick the sort of equipment you wish to transport (up to 1322 pounds).

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV

Winch installation is simplified with mounts and conduits pre-wired for a winch. Service reminders based on mileage or time may be set up on the multi-function instrument panel, which has been redesigned for improved aesthetics and visibility. The speedometer, odometer, trip meter, fuel level, hour meter, clock, range, and drive mode are shown on the instrument panel’s LCD screen. High, low, neutral, reverse and 2WD/4WD LED indications and LED warnings for fuel injection and engine temperature are all included. 2WD/4WD and differential-locked 4WD also have LED indicators.

An 18-amp maintenance-free battery is fed by a high-output, three-phase charging system for simple starting and accessory usage. There is a typical sealed 12V auxiliary outlet. Low-center-of-gravity positioning of the 4.6-gallon gasoline tank guarantees a smooth ride. A vacuum petcock and ratchet-style filler cap are included (which prevents over-tightening so it can be easily unscrewed for refilling). The back of the quad bike has a big 4.0-liter storage compartment, which is positioned next to the current-liter left-side chamber, allowing for plenty of storage space. An all-new screw-on lid makes it simple to reach the 2.8-liter water-resistant front storage section.

For long-lasting durability and scratch resistance, the steel-tube cargo racks have wrinkle paint finishes. Protective flooring with built-in elevated foot pegs is available. Some Suzuki Genuine Accessories feature a snow plow with a fast release, windshields, front and rear bumpers, metal skid pans and rack extensions.

Special Features

A 12-month warranty is included. Suzuki Extended Protection offers extended coverage durations and additional advantages (SEP). Operators must be at least Sixteen years old to operate.

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV – Price

The new Suzuki 2020 King Quad 750AXi Power Steering SE Utility Quad Bike is available at $9,949 only.

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV – Technical Specifications

Engine

Engine 722cc (44.1 cubics in.), 4-stroke, 4-valve, single-cylinder, liquid-cooled, DOHC
Bore x Stroke Ratio 104mm x 85mm (4.094 in. x 3.346 in.)
Compression Ratio 9.9:1
Fuel System Suzuki electronic fuel injection
Starter Electric
Lubrication Wet sump

Suzuki 2020 King Quad 750AXi Power Steering SE Utility ATV

DriveTrain

Transmission Automatic variable ratio (V-belt), having high/low-range and reverse
Clutch Dry shoe, automatic, centrifugal type
Driven Wheels 2WD, 4WD, and 4WD Differential Lock
Final Drive Shaft drive

Chassis

Suspension Front Independent, double wishbone, coil spring, gas-charged & oil damped having 5-way preload adjustable shock absorbers
Suspension Rear Independent, coil spring, double wishbone, gas-charged and oil damped having 5-way preload adjustable shock absorbers
Brakes Front Disc brakes, twin rotors
Brakes Rear Sealed oil-bathed multi-disc
Tires Front AT25 x 8-12, tubeless type x 2
Tires Rear AT25 x 10-12, tubeless type x 2
Fuel Tank Capacity 17.5 L (4.6 US gal.)
Color Solid Special White No. Two

Electrical Features

Ignition Electronic ignition (transistorized)
Headlight 12V 35/35W x 2 fender-attached, 12V 35W x 1 handlebar-attached
Tail Light LED

Dimensions

Overall Length 2150mm (84.6 inches)
Overall Width 1215mm (47.8 inches)
Overall Height 1285mm (50.6 inches)
Wheelbase 1285mm (50.6 inches)
Ground Clearance 260mm (10.2 inches)
Seat Height 920mm (36.2 inches)
Curb Weight 327 kg (721 lb.)

Warranty Options

Warranty 12 months of limited warranty available
Extension Coverage extension & additional benefits are available
