2017 KingQuad 750AXi Power Steering Special Edition Review

The all-new 2017 KingQuad 750AXi Power Steering Special Edition is incredible ATV that Suzuki Company has recently launched. The Suzuki Brand is very famous in the world of ATVs when it launched its first ATV in 1983. Today it is everywhere in the world of quad bikes. The new 2017 KingQuad 750AXi Power Steering Special Edition has a powerful engine of 722 ccs which fuel injected technology that provides incredible handling, and it also reduces the turning efforts. The new 2017 KingQuad 750AXi Power Steering Special Edition has easily adjustable suspension which supports rider to float over the rough surfaces without any problem. The new 2017 KingQuad 750AXi Power Steering Special Edition has an amazing color of Solid Matte Sword Black which makes it different from other quad bikes.

2017 KingQuad 750AXi Power Steering Special Edition

2017 KingQuad 750AXi Power Steering Special Edition – Specs and Price

Engine

The new 2017 KingQuad 750AXi Power Steering Special Edition comes with an incredibly powerful engine of 722 ccs with DOHC and single cylinder technology. The engine is liquid cooled and has got four strokes to delivers power to the wheels. The engine provides a strong low-to-mid range torque as well as high rpm power. The cylinder and its head are canted forward for the low center of gravity which reduces the engine height and lowers the seat height. The high mount air intake incredibly avoids water and debris. The 4-valve cylinder of the engine head has got large 36 mm intake valve and the straight ports for efficient cylinder charging. The quad bike has a chain and gear camshaft drive system which creates a compact cylinder head. The new 2017 KingQuad 750AXi Power Steering Special Edition has a lightweight aluminum cylinder which uses Suzuki Composite Electrochemical Material coating for the transfer of heat and the sealing of rings results in better combustion chamber efficiency. The engine of the new ATV 2017 KingQuad 750AXi Power Steering Special Edition also has a dual balancer shaft for smooth operation. The new quad bike has a high capacity of an aluminum radiator with the large diameter. Stable engine operating temperature is only possible with the help of the thermostatically controlled fan.

2017 KingQuad 750AXi Power Steering Special Edition

Transmission

The new 2017 KingQuad 750AXi Power Steering Special Edition comes with the automatic QuadMatic™ CVT-type transmission which provides versatility and convenience with the fender attached gate type shifter for high or low range selection. It has modified engine braking system which minimized the free-wheeling with the throttle off, and it also helps to control the vehicle during steep descents. The new quad bike has a torque sensing limited slip front differential that offers reliable traction augmented by the power steering system. The differential lock system delivers serious four-wheel-drive traction. The handlebar comes with the push button control which permits easy selection between 2 WD, 4 WD, and the differential lock. The override button is on the left handlebar is very handy especially when the bike stuck in the mud.

2017 KingQuad 750AXi Power Steering Special Edition

Chassis

The new 2017 KingQuad 750AXi Power Steering Special Edition has an independent double A-arm front suspension which features 6.7 inches of wheel travel that includes large diameter shock absorber with the 5-way spring preload adjustment. The new 2017 KingQuad 750AXi Power Steering Special Edition has fully independent, A-arm/I-beam rear suspension which features a7.7 inches of wheel travel that includes the large diameter shock absorber with the 5-way spring preload adjustment and the large diameter rear sway bar. The new 2017
KingQuad 750AXi Power Steering Special Edition has a dual hydraulic front disc brakes plus a sealed, multi-plate rear braking system. The design of the rear brake is a clutch type which gives high durability and low maintenance. The quad bike comes with the excellent traction CARLISLE tires of 25 inches which are attached to ultra-sturdy aluminum rims. The T-shaped seat of the new 2017 KingQuad 750AXi Power Steering Special Edition provides the rider mobility during the spirited of challenging terrain riding. The polyethylene skid plated provides the protection with minimum resistance over rocks and other rough surfaces. The plastic guards protect the front and rear half shafts.

2017 KingQuad 750AXi Power Steering Special Edition

Other features

The new 2017 KingQuad 750AXi Power Steering Special Edition comes with exceptional features. The quad bike got winch-ready mounts are wire conduit which creates the installation of winch very simple. The high trail hitch attaches with bracket are willing to accept the number one type ball. The instrument connected with new 2017 KingQuad 750AXi Power Steering Special Edition are LCD readouts for speedometer, twin trip meter, odometer, hour meter, driving range. The LED cautions for fuel injection and the temperature of the engine. This ATV comes with twin 30W halogen headlight with compact 5/21W taillight and brake light. The quad bike has the 18-amp maintenance-free battery for abundant power for easy starting and accessory use. The new 2017 KingQuad 750AXi Power Steering Special Edition has a large 17.5 liters of the fuel tank which is placed for a low center of gravity. It also contains vacuum operated petcock and a ratchet style filler cap. The generous 2.8 liters of water resistant front big tank includes an easy access screw on cap. The quad bike has a steel tube cargo racks which have wrinkle paint finish for durable and scratch free. The number of Suzuki Genuine Accessories are also available. The new 2017 KingQuad 750AXi Power Steering Special Edition has a limited warranty of 12 months.

2017 KingQuad 750AXi Power Steering Special Edition

2017 KingQuad 750AXi Power Steering Special Edition –Price

The new 2017 KingQuad 750AXi Power Steering Special Edition comes with the price tag of 9,599 only.

2017 KingQuad 750AXi Power Steering Special Edition – Specs

Engine

Type 722 cc (44.1 cm. in), 4-stroke, liquid cooled, DOHC, single cylinder
Bore x Stroke 104.0mm (4.094 inches)x 85.0mm (3.346 inches)
Ratio of Compression 10.0:1
Starter Electric
Lubrication Fuel System
Suzuki Fuel Injection Wet Sump

2017 KingQuad 750AXi Power Steering Special Edition Specs

Drive Train

Transmission CVT (V-belt), with high or low range and reverse
Driven Wheels 2WD, 4WD & 4WD Differential Lock
Final Drive Shaft drive

2017 KingQuad 750AXi Power Steering Special Edition Specs

Chassis

Suspension Front Independent, double wishbone, coil spring
Suspension Rear Independent, double wishbone, coil spring
Front Brakes Disc brakes, twin rotors
Rear Brakes Sealed oil-bathed multi-disc
Tires Front AT25 x 8-12, tubeless type x 2
Tires Rear AT25 x 10-12, tubeless type x 2
Fuel Tank Capacity 17.5 Liter
Color Solid Matte Sword Black

2017 KingQuad 750AXi Power Steering Special Edition Specs

Electrical

Ignition Electronic ignition (CDI)
Headlight 12V 35/35W (HS1) × 2
Tail Light 12V 21/5W

Dimensions

Overall Length 2115 mm (83.3 inches)
Overall Width 1210 mm (47.6 inches)
Overall Height 1285 mm (50.6 inches)
Wheelbase 1285 mm (50.6 inches)
Ground Clearance 260 mm (10.2 inches)
Seat Height 920 mm (36.2 inches)
Curb Weight 305 kg (672 lbs)

2017 KingQuad 750AXi Power Steering Special Edition Specs

Warranty

Warranty 12-month, unlimited mileage, limited warranty
Extensions Extensions available through the Suzuki Extended Protection (SEP)

Conclusion

The newly launched 2017 KingQuad 750AXi Power Steering Special Edition is an excellent ATV with fantastic design and solid black color, the powerful engine of 722 cc’s,  the great frame with exceptional features. The review, specification, and price of 2017 KingQuad 750AXi Power Steering Special Edition have been covered here on the best site www.bikescatalog.com.

2017 KingQuad 750AXi Power Steering Special Edition

This article is about the newly launched ATV by Suzuki Brand. 2017 KingQuad 750AXi Power Steering Special Edition is a fantastic ATV which has some outstanding features. So purchase the new 2017 KingQuad 750AXi Power Steering Special Edition and enjoy its ride anywhere you want to ride no matter whether you ride on the rough surfaces, rocks or in the mountains. Don’t forget to come again for the review of some other fantastic dirt or quad bikes and sports bike and leave your comments.
